Ductwork Installation

Age and material tell you a lot. Original 1960s–80s duct board and early flex in central Phoenix and Mesa homes is often at the end of its service life — the inner liner delaminates, insulation compresses, and the outer jacket goes brittle in attic heat. Once flex duct starts shedding, patching individual runs is money into a system that will keep failing.

Design problems also call for replacement rather than repair: too few returns, trunk lines undersized for the equipment, long crushed runs pinched between trusses, or a plenum transition so abrupt that airflow never recovers. You cannot seal your way out of a sizing error.

Repair or seal instead when the layout is sound and the problem is localized: a disconnected boot, a few open seams, a run crushed under stored boxes, or missing insulation on an otherwise healthy trunk. A ductwork inspection is what tells the two situations apart, and we would rather sell you the smaller job when the smaller job is the answer.

Design follows the load, not the old layout. Room-by-room load calculations set how much air each space needs, and duct sizing follows from that airflow using standard friction rate methods — not from whatever diameter the original installer had on the truck.

Return capacity is where most Valley homes fall short. A system with one undersized central return cannot move the air its blower is rated for, which raises static pressure, lowers airflow per ton, and produces both the weak-cooling complaint and the frozen-coil complaint. Adding return area is frequently the highest-value change in the entire project.

Then routing and materials: shortest practical runs, gentle radius bends instead of hard elbows, properly supported flex with no sag or kink, sealed metal trunk where it belongs, R-8 insulation on attic runs, and register and grille sizing that does not create noise at the airflow the room needs. Everything gets sealed with mastic — not tape alone, which fails in attic heat.

Most single-system residential duct replacements take one to three days depending on attic access, home size, and whether ceilings need opening for new returns. We protect flooring and work areas, stage the work so the home is not without cooling any longer than necessary, and haul away the old material.

At completion you should receive numbers, not assurances: total external static pressure before and after, airflow at the equipment, temperature split, and a walkthrough of the register balance room by room. If someone replaces your ductwork and hands you no measurements, there is no way to know whether the new system performs better than the old one.

We pull permits where required and coordinate with the equipment side of the project when both are being done together — which is the ideal sequence, since equipment sizing should be based on the duct system you are actually going to have.
